CARBOLITE GERO AX030-230SN Fan Assisted Bench Top Oven 30L

Product Description

The Apex AX Series Ovens are a range of 250°C laboratory ovens, comprising three bench-top sized models that are equipped with the R38 digital PID temperature controller.

Standard features

  • 250°C maximum operating temperature
  • 30, 60 or 120 litres chamber volumes
  • Equipped with the R38 digital PID temperature controller
  • Fan convection for rapid heating & excellent uniformity
  • Chemically resistant stainless steel liner
  • Two adjustable nickel-chrome plated wire shelves
  • Lever latch door & airtight silicone seal
  • Compliant with safety standard BS EN 61010-2-010:2003

Options

  • Over-temperature protection (recommended to protect valuable contents & for unattended operation)
  • Digital countdown timer to switch oven off
  • Additional sets of shelves & runners
  • Lockable door
  • Low voltage options for use below 220 V
  • Routine spares kit

LABORATORY OVEN - AX TECHNICAL DATA

AX30 AX60 AX120
Max temp 250°C 250°C 250°C
Min temp Ambient +30°C Ambient +30°C Ambient +30°C
Volume (litres) 28 66 128
Temp uniformity (°C) ±5.0 @ 250°C ±5.0 @ 250°C ±5.0 @ 250°C
Heat-up time (mins) 23 25 26
Recovery time (mins) 3 3 3
Dimensions:
Internal H x W x D (mm)
295 x 300 x 320 395 x 400 x 420 495 x 500 x 520
Dimensions:
External H x W x D (mm)
440 x 590 x 465 540 x 690 x 565 640 x 790 x 665
Shelves fitted / accepted 2 / 4 2 / 6 2 / 8
Shelf loading each / total (kg) 10 / 20 10 / 30 10 / 40
Air changes / hr 65 28 14
Max power (W) 1000 1500 2000
Holding power (W) 342 465 622
Weight (kg) 24 37 55

Please note
- Uniformity is measured in an empty chamber with vents closed, after a stabilisation period
- Shelf loadings are based on evenly distributed weight
- Maximum power and heat up times based on a 240V supply
- The uniform volume is smaller than the total chamber volume
- Minimum operating temperature is ambient +30°C

Content may be subject to modifications or corrections
